FITUR :
– Complies with IEEE802.3, IEEE802.3u standards
– Supports auto MDI/MDI-X crossover detecting and auto correction
– Supports IEEE802.3X flow control for full duplex and back pressure flow control for half duplex
– Wire speed packet filtering and forwarding rate
– Store and forward architecture filters fragment & CRC error packets
– Supports IEEE802.3az energy efficient Ethernet

SPESIFIKASI :
Standards
– IEEE 802.3 10BASE-T
– IEEE 802.3u 100BASE-TX
– IEEE 802.3x Flow Control
– IEEE 802.3az Energy Efficient Ethernet
Features
– RJ-45 Port:16
– MAC Address: 8K
– Buffer Memory: 256K
– Transmission Method: Store and Forward
Filtering / Forwarding Rates
– 100Mbps Port 148,800pps
– 10Mbps Port 14,880pps
Transmission Media
– 10BASE-T Cat. 3, 4, 5 UTP/STP
– 100BASE-TX Cat. 5 UTP/STP
LED Indicators
– Per Port: Link/Act
– Per Unit: Power
Power Requirement : DC 5V 1A
Power Consumption : 1.72Watts (Max)
Dimension : 160 107 40mm (L x W x H)
Weight : 0.215 kg
Temperature :
– Operating: 0 to 40
– Storage: -20 to 70
Humidity :
– Operating : 10 to 90% RH (Non-condensing)
– Storage: 5 to 90% RH (Non-condensing)
Certifications : CE, FCC
