Spesifikasi :
– Tampilan : 4 10/100/1000Mbps Port LAN, 1 10/100/1000Mbps Port WAN, 2 Port USB 2.0
– Tombol : Tombol WPS/Reset, Switch On/Off Wireless, Tombol Power On/Off
– Catu Daya Eksternal : 12VDC / 2.5A
– Dimensi(WXDXH) : 9.6×6.4×1.3 in. (243×160.6×32.5mm)
– Tipe Antena : 3 antena detachable 5dBi 5GHz (RP-SMA), 3 internal antena 2.4GHz
– Standar Wireless : IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
– Frekuensi : 2.4GHz and 5GHz
– Tingkat Signal : 5GHz: Sampai Dengan 1300Mbps, 2.4GHz: Sampai Dengan 450Mbps
– Penerimaan Sensitivitas :
5GHz : 11a 6Mbps-96dBm
11a 54Mbps: -79dBm
11ac HT20: -71dBm
11ac HT40: -66dBm
11ac HT80: -63dBm
2.4GHz, 11g 54M: -77dBm
11n HT20: -74dBm
11n HT40: -72dBm
– Transmit Power : 20dBm (EIRP)
– Fungsi Wireless : Aktif/Non Aktif Wireless Radio, WDS Bridge, WMM, Wireless Statistics
– Keamanan Wireless : Enkripsi 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK
– Tipe WAN : Dynamic IP/Static IP/PPPoE/ PPTP(Dual Access)/L2TP(Dual Access)/BigPond
– DHCP : Server, Client, DHCP Client List, Address Reservation
– Quality of Service : WMM, Bandwidth Control
– Port Forwarding : Virtual Server, Port Triggering, UPnP, DMZ
– Dynamic DNS : DynDns, Comexe, NO-IP
– VPN Pass-Through : PPTP, L2TP, IPSec
– Access Control : Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
– Keamanan Firewall DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
– Protokol : DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
– USB Sharing : Support Samba(Storage)/FTP Server/Media Server/Printer Server
– Manajemen : Access Control, Local Management, Remote Management
– Guest Network : 2.4GHz guest network 1, 5GHz guest network 1
