– Built-in 16dBi 2×2 dual-polarized directional MIMO antenna
– Adjustable transmission power from 0 to 27dBm/500mw
– System-level optimizations for more than 20km long range wireless transmission
– TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
– Centralized Management System Pharos Control
– AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
– Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

Spesifikasi :
– Processor : Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
– Memory : 64MB DDR2 RAM, 8MB Flash
– Interface : 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in), 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough), 1 Grounding Terminal, 1 Reset Button
– Power Supply : Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins), Voltage range: 16-27VDC
– Power Consumption : 14 Watts Max, Note: When deployed using Passive PoE, the power drawn from the power source, will be higher by some amount depending on the length of the connecting cable.
– Dimensions ( W x D x H ) : 113.12.4 inch (2767960mm)
– Antenna Type : Built-in 16dBi 2×2 Dual-polarized Directional Antenna, Beam Width: 45 (H-Plane) / 30 (E-Plane), Note: For more details, please refer to datasheet
– Protection : 15KV ESD Protection 6KV Lightning Protection
– Interfaces : 1 AC Jack with Earth Ground, 1 10/100/1000Mbps Shielded Ethernet Port (Power + Data), 1 10/100/1000Mbps Shielded Ethernet Port (Data)
– Button : Remote Reset Button
– Certification : CE, FCC, RoHS, IPX5
– Package Contents : Outdoor Wireless CPE, 24V 1A Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide
