HARDWARE FEATURES Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p Interface 5 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100 STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100 STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100 STP (maximum 100m) Fan Quantity Fanless Power Supply 100-240VAC, 50/60Hz Dimensions (W X D X H) 3.9 * 3.9 *1.0 in. (100 * 98 *25 mm) PERFORMANCE Packet Forwarding Rate 7.4Mpps MAC Address Table 2K Packet Buffer Memory 1.5Mb Jumbo Frame 15KB SOFTWARE FEATURES Quality of Service Support Port-based/802.1p/DSCP priority 2 Support 4 priority queues Rate Limit Storm Control L2 Features IGMP Snooping Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN Transmission Method Store-And-Forward
