Deskripsi

Model Name
XT8 (B-1-PK)
XT8 (B-2-PK)
XT8 (W-1-PK)
XT8 (W-2-PK)
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IPv4
IPv6
AX technology
Yes
Data Rate
802.11n : up to 300 Mbps
802.11ac (1024QAM) : up to 3466 Mbps
802.11ax (2.4GHz) : up to 574 Mbps
802.11ax (5GHz) : up to 4808 Mbps
Antenna
Internal antenna x 6
Transmit/Receive
2.4 GHz 2 x 2
5 GHz-1 2 x 2
5 GHz-2 4 x 4
Processor
1.5 GHz quad-core processor
Memory
256 MB Flash
512 MB RAM
Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth
Operating Frequency
2.4G Hz, 5 GHz-1, 5 GHz-2
Ports
RJ45 for 2.5G BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3
USB 3.1 Gen 1 x 1
Button
WPS Button, Reset Button, Power Switch
LED Indicator
Power x 1
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A current
Package content
ZenWiFi AX
RJ-45 Cable
Power Adapter
Quick Start Guide
Warranty Card
Product Weight (g) 716 g
Wireless
IPv6:Yes
MU-MIMO:Yes
Wi-Fi Encryption:WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support
UTF-8 SSID:Yes
Guest Network:Yes
Maximum Guest Network rule:Max 9 rules
WPS:Yes
Wi-Fi MAC address filter:Yes
Maximum MAC filters:Max 64 rules
USB application
File System:FS_Tuxera_HFS+, FS_Tuxera_NTFS, FS_Tuxera_vFAT, FS_ext2, FS_ext3, FS_ext4
Administration
Operating mode:Wireless router mode
Range extender mode
Access point mode
Media bridge mode
Firewall:Yes
Maximum Firewall keyword filter:Max 64 rules
Maximum Firewall network service filter:Max 32 rules
Maximum Firewall URL filter:Max 64 rules
