Technical Specifications
Hardware
RF: 2.4 GHz Frequency Band
Standard: IEEE 802.11b/g/n
IEEE 802.11b/g: 2.400~2.484 GHz
Data Rate: Up to 300 Mbps
Memory: 32MB
Flash Memory: 4MB
Power Consumption: Up to 9W

Antenna
Internal 5 dBi Omni-Directional Antenna (diversity support)

Physical Interface
1 x RJ-45 Gigabit Ethernet (10/100/1000 Mbps)
1 x Reset Button
Power Jack

LEDs Status
Power
LAN (10/100/1000 Mbps)
WLAN (Wireless Connection)
Power Requirements
Power Supply: 90 to 240 VDC 10%, 50/60 Hz
(depends on different countries)
Active Ethernet (Power-over-Ethernet, IEEE 802.3af)
Power Adapter (United States) 48VDC/0.375A
Device: 12V/1A

Modulations
OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK
Operating Channels
2.4 GHz: US/Canada 1-11
Receiver Sensitivity
802.11b (2.412~2.472 GHz) best -98 dBm
802.11g (2.412~2.472 GHz) best -93 dBm
802.11n (2.412~2.472 GHz) best -93 dBm

Available Transmit Power
(Max. Power may be different depending on local regulations)
802.11b (2.412~2.472 GHz)
29 dBm @ 1~11 Mbps
802.11g (2.412~2.472 GHz)
29 dBm @ 6 Mbps
29 dBm @ 9 Mbps
28 dBm @ 12 Mbps
28 dBm @ 18 Mbps
24 dBm @ 24 Mbps
24 dBm @ 36 Mbps
23 dBm @ 48 Mbps
23 dBm @ 54 Mbps
802.11n (2.412~2.472 GHz)
26 dBm @ MCS0/MCS8
26 dBm @ MCS1/MCS9
25 dBm @ MCS2/MCS10
25 dBm @ MCS3/MCS11
24 dBm @ MCS4/MCS12
24 dBm @ MCS5/MCS13
23 dBm @ MCS6/MCS14
23 dBm @ MCS7/MCS15
ftware
Topology
Infrastructure/Ad-Hoc
Operation Modes
Access Point, WDS Bridge, WDS Access Point, Universal Repeater
Mutliple BSSID
Supports up to 8 SSIDs
LAN
IP (check validity and DHCP server IP range)
DHCP Server
DHCP range, lease time, client list
