Hardware
Chipset : MTK7628
Flash : Default 4MB SPI Nor Flash
SDRAM : Default 32MB SDRAM
Interface : 2 *100BaseTX (Auto MDI/MDIX) LAN Port (Passive PoE Supported)
Power Supply : 24V DC /0.5A (PoE)
Button : 1 *Reset Button
Antenna : 2 *12dBi internal antennas
LED Indicators : 1 *Power, 1 *LAN, 1 *LAN2,,2 *Signal Strength
Environment :
– Operating Temperature: 0?~40? (32?~104?)
– Storage Temperature: -40~70? (-104?~158?)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~95% non-condensing

Wireless
Standards : IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3u, IEEE 802.3
RF Frequency : 2.4~2.4835GHz
Data Rate :
– 802.11n: up to 300Mbps
– 802.11g: up to 54Mbps (dynamic)
– 802.11b: up to 11Mbps (dynamic)
Wireless Security :
– 64/128-bit WEP, WPA/WPA2, WPA-Mixed
Channels : 1-11 (North America), 1-13 (General Europe), 1-14 (Japan)
Modulation Type : DBPSK, DQPSK, CCK and OFDM (BPSK,QPSK,16-QAM/ 64-QAM)
Reception Sensitivity :
– 11M: -81 dBm@10% PER
– 54M: -68 dBm@10% PER
HT20 MCS7: -65 dBm@10% PER
HT40 MCS7: -62 dBm@10% PER

Software
System Status : A summary of wireless status
Operation Mode :
– AP Mode
– Repeater Mode
– Client
– Bridge
– AP+ Client
– Bridge+Client

Network :
– LAN Setting
– Static DHCP Setup

Wireless :
– Basic Setting
– Advanced Setting
– Basic Setting
– Advanced Setting
– Country Region
– Band
– Channel
– DFS
– TX/RX Chain
– Distance
– RF output power

Management :
– Basic Setting
– Upgrade Firmware
– Save/ Reload Setting
– Time Zone Setting
– Password Setting
– System Log
– logout
