Features

-Standard IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3 and IEEE 802.3u

-Three kinds operating mode: Router, Client, AP

-Select operating mode by up/down slide switch

-Support 64/128 bits WEP data encryption, and WPA,WPA2,WPA&WPA2 data encryption

-One self-adaption Ethernet port

-Support cable/XDSL MODEM, Static & Dynamic IP multiple ways for broadband access

-Support remote/ local WEB management

-Automatic identify cross and direct network cable

-Support Access Control of Internet in LAN

-Support WDS extension of wireless network



Specifications :



Wireless Standards :

IEEE 802.11n (draft)

IEEE 802.11g

IEEE 802.11b



Frequency Band :

802.11n: up to 150Mbps (downlink) and

150Mbps (uplink)

802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6

Mbps auto fallback

802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback



RF Frequency :

2412 ~ 2462 MHz (North America)

2412 ~ 2472 MHz (Europe)

2412 ~ 2484 MHz (Japan)



Radio Channel : 1 ~ 14 channels (Universal Domain Selection)

Chipset : Ralink7601

Range Coverage : Up to 3 times farther range than 802.11g

Antenna type : Integrated Antenna

Roaming : Full mobility and seamless roaming from cell to cell

RF Output Power : 13 ~17 dBm (Typical)



Modulation :

11n: BPSK, QPSK, 16QAM, 64QAM with

OFDM

11g: BPSK, QPSK, 16QAM, 64QAM, OFDM

11b: DQPSK, DBPSK, DSSS, CCK



Data Security :

64/128-bit WEP Encryption

WPA, WPA-PSK, WPA2, WPA2-

PSK. TKIP/AES



Network :

Auto-switch to use 802.11n or

802.11g or 802.11b mode

Supports Ad-Hoc, Infrastructure

WLAN network

Wireless roaming

Data rate auto fall-back under noisy

environment or longer range

distance

Site Survey with Profile function



Configuration & Management :

Plug-and-Play setup and installation

Management Utility supports 2000 /

XP/ Vista



Media Access Control : CSMA/CA with ACK

LED Indicator :Link/Active ( Green )
